22EDM12-050020A0101A2
end drive conveyor with V-guide belt tracking, 12in (305mm) wide x 5.00ft (1524mm) long, drive shaft in position A with type 01-low side profile on both sides and belt type 02, General Purpose with plastic clipper splice. Configuration includes standard drive and idler tail and mounting brackets. Weight = 46lb (21kg).
22MFEK12A-4416
Standard Load 90 Degree flush Bottom mount package for a end drive conveyor, mounted in the A position, 44:16 pulley ratio.
32M020EL423EN
Standard load E-Drive 90 Degree VFD Indexing, Variable Speed gearmotor, .5 Hp (.37kw), 230/460 volt, 3 phase, 6-60 Hz, 86 RPM, providing a belt speed of 8 - 83 ft/min (2.4 - 25.3 m/min). Order variable speed controller separately.
39MAH12-2436F
Adjustable Height Stand with fixed foot pads for up to a 12in (305mm) wide conveyor. Stand is adjustable from 24in (610mm) to 36in (914mm). Stand has a base width of 13.5in (343mm).
39MB-TS
Diagonal bracing for H style stands up to 30in (762mm) tall.
